SYSTEM PLUS®

SYSTEM PLUS®

UN-approved one-piece aluminum bottle, designed to protect sensitive or hazardous liquids. This tamper-evident range offers three opening sizes, adapted to the requirements of the most demanding markets.

Capacities

Closure

  • PP screw cap, with Alu/PE liner or PTFE and tamper-evident collar
  • For SYSTEM PLUS® 32 internal neck diameter 22 mm;
  • For SYSTEM PLUS® 45 internal neck diameter 28 mm;
  • For SYSTEM PLUS® 62 internal neck diameter 46 mm
  • PE plugs with pull ring for each opening.

Uses

Packaging, storage, transport and sampling of sensitive materials with various viscosities.

EXPERTISES

THE BENEFITS OF THE RANGE

Discover the main features of this product range.

Tightness

SYSTEM PLUS® offers excellent tightness thanks to its robust and ergonomic closing system, its compressible Alu/PE liner resistant to solvents, and its dedicated tightening accessories.

Its one-piece aluminum structure, without welding, guarantees maximum protection for sensitive liquids by shielding them from gas and light.

This level of protection significantly reduces the risk of leakage or non-conformity and ensures reliable and safe logistics, even in the most demanding transport conditions.

Compatibility

Made of pure aluminum, SYSTEM PLUS® bottles guarantee high chemical inertness, furthered enhanced by controlled pickling. They are compatible with a wide range of products, including food products, depending on the selected internal finish (plain aluminum or varnish).

Several types of internal varnishes are available to meet the requirements of aggressive products or products sensitive to aluminum. In all cases, compatibility tests must be carried out by the user.

Cleanliness

With nearly 200 years of experience, Tournaire is a recognized expert in cleanliness. Thanks to controlled washing processes of aluminum and strictly controlled manufacturing, our packaging reaches chemical, microbiological and particulate cleanliness levels among the highest on the market. Our bottles smooth surface, without areas of retention, guarantee optimal protection of your sensitive liquids and preserves their integrity.

Regulatory

This range is UN-approved for the transport of dangerous liquids, and solids for some models, having successfully passed drop and pressure resistance tests that guarantee safety and reliability. Some finishes are suitable for food contact. Certain models have Drug Master Files (DMF) registered with the Chinese Food and Drug Administration (CFDA) in China. The SYSTEM PLUS® 62 7L model with handle also has a DMF registered with the U.S. FDA.

Contact us to consult the general certificate.

Safety

SYSTEM PLUS® offers optimal resistance to shocks, punctures and compression that may occur during transport, ensuring the safety of products in accordance with the UN standards. Thanks to its tamper-evident tab and its plug, the closing system is secured, with the option to add a security seal on certain references.

Colored caps and threads make it easy to differentiate the different products contained.

To complete the solution, UN-certified cartons suitable for the transport of dangerous goods can be supplied.

Sustainability

The SYSTEM PLUS® range is a safe alternative to HDPE cans, varnished steel or glass, while being 25-40% lighter at equal volume, which makes handling easier and reduces supply chain costs.

FINISHES

OUR CUSTOM OPTIONS

Our packaging can be configured to meet your product requirements.

Finishing option

The SYSTEM PLUS® range is available in plain aluminum, with a high-resistance epoxy-phenolic internal varnish, or a food-grade BPA-NI internal varnish, in order to meet product compatibility and regulatory requirements. From 2.5 L, the bottle can be fitted with an integrated handle to facilitate handling. A security seal is also available to guarantee content integrity and prevent any tampering.

Customisation

Customization is possible through several marking options: pad printing on caps (logo or specific markings), external lacquering, silk screening on the bottle body. The cap and the threads are available in different colors, allowing the packaging to be customized to reflect your brand identity, create product ranges or enable quick product differentiation.

Contact our experts to detail your tailor-made requirements

RANGE FROM 50 ML TO 32 L

RANGE FROM 50 ML TO 32 L

Capacity (cc)Inner neck diameter (mm)Weight (g)UN-approvalQuantity per carton and per pallet
502229Liquid430 - 5160
1252238Liquid348 - 6960
1602243Liquide348 - 5916
2752250Liquid250 - 3500
3152253Liquid250 - 3250
6252279Liquid160 - 1600
110022107Liquid110 - 880
6252890Liquid160 - 1600
110028120Liquid110 - 880
125028141Liquid110 - 770
250028229Liquid60 - 420
400028306Liquid26 - 208
550028304Liquid13 - 156
625028419Liquid26 - 156
125046166Liquid - Solid110 - 770
250046258Liquid - Solid60 - 420
400046346Liquid - Solid26 - 208
550046326Liquid26 - 156
625046466Liquid26 - 156
1250046776Liquid9 - 90
20000461236Liquid2 - 44
25000461486Liquid2 - 44
32000461666Liquid2 - 33
TO COMPLETE YOUR SOLUTION

Related solutions

VIEW ALL ACCESSORIES
view more

OTHERS SOLUTIONS FOR YOUR NEEDS

Discover the full range

YOUR PACKAGING QUESTIONS

What are the differences between the SYSTEM PLUS® 32, 45, and 62 models?

SYSTEM PLUS ® models are distinguished by three opening sizes: the 32 model is intended for small quantities of liquids, the 45 model for intermediate volumes, and the 62 model is suitable for bulk volumes up to 32 L, with an internal opening of about 46 mm and an optional handle depending on the reference.

Do you have models available with UN approval?

Yes, the entire SYSTEM PLUS® range is UN-approved for the transport of dangerous liquids. Some models also have UN approval for the transport of solids. Contact our experts to confirm the approval status and the level of specific models.

What tightening torque should I close the bottle with?

Each SYSTEM PLUS® bottle must be closed in accordance with the recommended tightening torque to guarantee tightness, safety and UN approval. These values are specified in the technical datasheet or can be provided by our experts on request.

Do you offer caps with certified child-resistant closure (CRC)?

The SYSTEM PLUS® range does not offer child-resistant closure. Only the CHEM 42 range is available with this type of closure.

Is the SYSTEM PLUS® range sterilizable?

The SYSTEM PLUS® range has not been designed with the aim of being sterilized. Indeed, the plastic parts (sleeves and caps) are particularly sensitive to temperature and ionizing radiation.

Are SYSTEM PLUS® bottles recyclable?

Aluminum bottles in the SYSTEM PLUS® range are made of pure aluminum, a 100% recyclable material. To guarantee total recycling, it is however necessary to remove the sleeve.

Do you offer customization options?

Yes, bottles in the SYSTEM PLUS® range can be customizable by lacquering, screen printing, pad printing of caps, sleeve and cap colors, accessories, etc. Consult our page dedicated to customization and contact our experts to develop your customized project.
